Home >> Antibodies >> IAP Antibody CD47/3019 / CD47 Monoclonal Antibody

IAP Antibody CD47/3019 / CD47 Monoclonal Antibody [clone CD47/3019] (V7535)

  Catalog No Formulation Size Price (USD)
Image V7535-100UG 0.2 mg/ml in 1X PBS with 0.1 mg/ml BSA (US sourced) and 0.05% sodium azide 100 ug 559
V7535-20UG 0.2 mg/ml in 1X PBS with 0.1 mg/ml BSA (US sourced) and 0.05% sodium azide 20 ug 259
V7535SAF-100UG 1 mg/ml in 1X PBS; BSA free, sodium azide free 100 ug 559
V7535IHC-7ML Prediluted in 1X PBS with 0.1 mg/ml BSA (US sourced) and 0.05% sodium azide; *For IHC use only* 7 ml 559
Microvalidated
Bulk quote request
IAP Antibody CD47/3019 in Human MCF7 Breast Cancer Cells IF. Immunofluorescence staining of paraformaldehyde-fixed human MCF7 breast cancer cells with IAP Antibody clone CD47/3019 (green) and RedDot nuclear stain (red). The image shows green CD47 signal distributed prominently around the cell periphery, with comparatively little overlap with the red nuclear staining. The membrane-associated pattern is consistent with the cell-surface localization of integrin-associated protein and demonstrates cellular detection with the CD47 Monoclonal Antibody.
IAP Antibody CD47/3019 in Human MCF7 Breast Cancer Cells FACS. Flow cytometry testing of human MCF7 breast cancer cells with IAP Antibody clone CD47/3019. The antibody-stained population (blue) shows a pronounced rightward fluorescence shift relative to the isotype control (red), with substantial separation between the two distributions. This strong shift demonstrates detection of endogenous cell-surface CD47 in MCF7 cells and supports use of the CD47 Monoclonal Antibody for flow cytometric analysis.
IAP Antibody CD47/3019 Shows Membranous Staining in Prostate Carcinoma IHC. Immunohistochemistry staining of FFPE human prostate carcinoma tissue with IAP Antibody clone CD47/3019. HIER was performed by boiling tissue sections in pH 9 10mM Tris with 1mM EDTA for 10-20 min followed by cooling before testing. Brown staining is prominent throughout the malignant glandular epithelium, with distinct labeling along epithelial cell membranes and additional cytoplasmic signal. The surrounding stromal tissue shows substantially less staining, supporting tumor epithelial detection with the CD47 Monoclonal Antibody.
IAP Antibody CD47/3019 Highlights Prostate Tumor Glands IHC. Immunohistochemistry staining of FFPE human prostate carcinoma tissue with IAP Antibody clone CD47/3019. HIER was performed by boiling tissue sections in pH 9 10mM Tris with 1mM EDTA for 10-20 min followed by cooling before testing. This second tumor field shows strong brown labeling of the glandular epithelial compartment, including prominent cell-border staining, while the intervening stromal areas remain comparatively lightly stained. The distribution further demonstrates tissue detection of integrin-associated protein with the CD47 Monoclonal Antibody.
IAP Antibody CD47/3019 Protein Microarray Validated. HuProt protein microarray analysis containing more than 19,000 full-length human proteins demonstrates highly selective recognition by IAP Antibody clone CD47/3019. CD47 ranks first with a Z-score of 65.3, compared with 20.48 for the next-highest protein, CD19, producing an S-score of 44.82. The Z-score measures signal strength in standard deviations above the array mean, while the S-score represents the difference between the target Z-score and the next-highest signal. This separation supports the specificity of the CD47 Monoclonal Antibody.
Purified IAP Antibody CD47/3019 SDS-PAGE. SDS-PAGE analysis of 2 ug purified, BSA-free IAP Antibody clone CD47/3019 under reducing (R) and non-reducing (NR) conditions. The non-reduced antibody migrates predominantly near 150 kDa, corresponding to intact immunoglobulin, while reduction produces the expected heavy and light chains at approximately 50 kDa and 25 kDa. The expected electrophoretic profile provides confirmation of integrity and purity for the CD47 Monoclonal Antibody preparation.
Availability 1-3 business days
Species Reactivity Human
Format Purified
Host Mouse
Clonality Monoclonal (mouse origin)
Isotype Mouse IgG1, kappa
Clone Name CD47/3019
Purity Protein G affinity chromatography
UniProt Q08722
Localization Cell surface, cytoplasmic
Applications ELISA : order BSA/sodium azide-free format for coating
Flow Cytometry : 1-2ug/million cells
Immunofluorescence : 1-2ug/ml
Immunohistochemistry (FFPE) : 1-2ug/ml for 30 min at RT
Limitations This IAP Antibody CD47/3019 / CD47 Monoclonal Antibody is available for research use only.
Review this product on BioCompare and get a $20 Amazon gift card

Related Products

Description

IAP Antibody CD47/3019 / CD47 Monoclonal Antibody recognizes integrin-associated protein (IAP), a widely expressed transmembrane glycoprotein encoded by the CD47 gene. CD47 was originally identified through its association with integrins and was consequently named IAP. Subsequent research established CD47 as a multifunctional cell-surface protein involved in immune recognition, cell adhesion, migration, and signal transduction. Its extracellular binding partners include signal regulatory protein alpha (SIRP alpha) and thrombospondin-1, connecting CD47 to several distinct biological pathways.

CD47 has an unusual membrane organization consisting of an extracellular immunoglobulin-like domain, five transmembrane segments, and a short alternatively spliced cytoplasmic tail. Its association with integrins and other membrane proteins allows CD47 to participate in multiprotein signaling complexes that regulate cellular adhesion, motility, survival, and responses to the extracellular environment. The historical IAP designation therefore remains biologically relevant because integrin-associated functions represent an important component of CD47 biology.

A major area of CD47 research concerns its interaction with SIRP alpha. Engagement of SIRP alpha on myeloid cells by CD47 can initiate inhibitory signaling that restrains phagocytosis, contributing to recognition of cells as self. This mechanism has attracted substantial interest in cancer biology because increased CD47 expression has been reported in numerous malignancies and may reduce macrophage-mediated elimination of tumor cells. An IAP Antibody can therefore support studies examining CD47 abundance and the cellular mechanisms associated with immune recognition.

CD47 also binds thrombospondin-1 and participates in pathways extending beyond the CD47-SIRP alpha axis. These interactions have connected CD47 with vascular biology, cellular stress responses, adhesion, migration, and tissue homeostasis. The biological consequences of CD47 activity depend on cell type, ligand availability, interacting membrane proteins, and the organization of surrounding signaling complexes.

The names IAP, integrin-associated protein, CD47, OA3, and MER6 reflect different stages in the discovery and characterization of this multifunctional membrane protein. NSJ Bioreagents offers clone CD47/3019 for research into CD47 expression, immune regulation, cell adhesion, and receptor-associated signaling.

An IAP Antibody such as clone CD47/3019 provides a monoclonal reagent for investigating integrin-associated protein expression and signaling, while a CD47 Monoclonal Antibody provides current cluster-of-differentiation terminology for studies of immune recognition, cell adhesion, and intercellular communication.

For a Protein Microarray Validated antibody targeting the same protein, see our CD47 Antibody CD47/2937 / IAP Monoclonal Antibody.

Application Notes

Optimal dilution of the IAP Antibody CD47/3019 / CD47 Monoclonal Antibody should be determined by the researcher.

1. The prediluted format is supplied in a dropper bottle and is optimized for use in IHC. After epitope retrieval step (if required), drip mAb solution onto the tissue section and incubate at RT for 30 min.

Immunogen

Amino acids 18-135 from the human protein were used as the immunogen for the IAP Antibody CD47/3019.

Storage

Store the IAP Antibody CD47/3019 at 2-8oC (with azide) or aliquot and store at -20oC or colder (without azide).

Alternate Names

CD47 antibody, Integrin Associated Protein antibody, OA3 antibody, MER6 antibody, Rh-Related Antigen antibody
